Alternating Current Meter Manufacturer
Delivering precise, durable, and customizable AC metering solutions trusted by global utilities and industrial users
D30162-Main paremeters
| Type | D30162 |
| Standards | EN 50470-3:2022,IEC 62052-31:2015 |
| Voltage | |
| Rated voltage Un | 230V |
| Voltage range | 100~275V |
| Current | |
| Minimum current Imin | 1.25A |
| Reference current Ib | 25A |
| Maximum current Imax | 100A |
| Rated Frequency Fn | 50Hz±1.75% |
| Accuracy | Class B/1.0 for active |
| Pulsating Indicator | LED |
| Pulsating(meter constant) | 1000imp/kWh |
| Environment | |
| Temperature range | Operation:-25~55℃ |
| Storage:-40~70℃ | |
| Protection Degree | IP 20 |
| Insulation Class | II |
| Typical Power Consumption | |
| Voltage circuit active/apparent power at Un | <2.4W/6VA |
| Current circuit apparent power at Ib | <1VA |
| Communication Interface | RS485-A/B with screw type |
| Weight Of Meter | About 0.15kg |
| Dimension(LxWxD) | 36×66×110mm |
We invite you to visit our testing workshop.
1. What are the metering accuracy and applicable scenarios for this electricity meter?
The D30162 has Class B/1.0 accuracy, meeting the precise electricity metering needs of households, shops, and small industrial and commercial scenarios. It offers long-term stability, is not prone to drift, and can meet the power monitoring needs of most projects.
2. Can the meter's maximum current of 100A handle high-power loads?
Yes. The Imax 100A design allows it to handle continuous high-load applications such as high-power home appliances, water heaters, air conditioners, electric vehicle slow charging, and small commercial equipment while maintaining stable metering performance.
3. Is the RS485 communication interface compatible with existing systems?
It supports RS485-A/B (screw terminal), is compatible with mainstream systems such as Modbus/DLMS, and can be directly connected to your AMI, meter reading system, smart distribution platform, etc., without the need for an additional protocol converter.
4. Can the meter operate normally in harsh environments?
Yes.
Its operating temperature range is -25℃ to 55℃, and its storage temperature range is -40℃ to 70℃. It features IP20 rating, dustproof design, and Class II insulation, making it suitable for engineering environments such as distribution boxes and low-voltage cabinets. It is resistant to temperature and humidity.
5. What are the installation and power consumption characteristics of the D30162? Will it increase power consumption?
The meter is compact (36×66×110mm), suitable for DIN rail mounting.
Power consumption is very low:
Voltage loop <2.4W/6VA
