Ethernet To RS485 Converter M50114-RSA Feature
● Ethernet to RS485 line conversion
● Connection to 10/100 Base-T Ethernet via RJ45 connector
● RS485 connected via a slip-on bus bar
● Used signals:RxTx+,RxTx-(or A,B)
● RS485 protection against overvoltage
● Automatic direction switching
● Secured against unauthorized access
● Power supply range:5 to 36V
● Indication of power supply,data transmission,network connection and activity
● Mountable to DIN rail
● Local configuration via WIFI,Ethernet
Product Parameters
| specification | M50114-RSA |
| voltage | 5~36V DC |
| LED Indicator | |
| PWR | power Indicator |
| COMM | communication indicator |
| LINK | Network indicator |
| ACTIVE | Network type indicator |
| operation Temperature | -25~75C |
| Humidity | 20%~90% |
| consumption | 12V,<80 mA |
| Baud Rate | 1200,2400,4800,9600,19200,38400,57600,115200, 384000,921600 |
| Local configuration | via wl FI,Ethernet |
FAQ
Q1: What is the input voltage range of this converter?
A1: The device supports a wide voltage range of 5–36V DC, ensuring flexible power supply options.
Q2: What type of indicators are available on the device?
A2: It includes Power (PWR), Communication (COMM), Network (LINK), and Network Type (ACTIVE) indicators for real-time status monitoring.
Q3: What is the operating temperature range?
A3: The converter works reliably in harsh environments with an operating range of -25°C to +75°C.
Q4: What is the humidity tolerance?
A4: It operates under humidity levels from 20% to 90%, suitable for diverse applications.
Q5: How much power does the device consume?
A5: Power consumption is less than 80mA at 12V, making it highly energy-efficient.
Q6: What baud rates does this converter support?
A6: It supports multiple baud rates including 1200, 2400, 4800, 9600, 19200, 38400, 57600, and 115200 bps.
Q7: How is local configuration carried out?
A7: Local configuration can be done via Wi-Fi or Ethernet, making setup simple and flexible.
