3 phase din rail meter Feature
High-precision measurement: The three-phase rail electric meter has an active power accuracy of up to 1.0S and a reactive power accuracy of 2.0, which can accurately capture power consumption data under different loads.
Convenient installation: It requires complex installation procedures. You only need to snap the meter into the rail to complete the basic installation. At the same time, it covers a variety of voltage and current specifications and can adapt to different power usage scenarios.
Rich functions: In addition to basic power metering, it also has a variety of additional functions such as harmonic detection, complex rates, and prepayment.
Good compatibility: The pulse output function also enables it to be linked with data collectors, control equipment, etc., to achieve integrated management such as remote meter reading and power consumption monitoring, and improve the overall power consumption management efficiency.
| Type | D3132 |
| standards | EN 50470-3:2022,IEC 62053-21/23:2020,IEC 62052-31:2015,UL61010-1,UL61010-2-030 |
| voltage | |
| Rated voltage un | 3x230/400v |
| voltage range | 70%un~140%un |
| current | |
| Minimum current Imin | 0.25A |
| Reference current Ib | 5A |
| Maximum current Imax | 80A |
| starting current ist | 0.4%Ib |
| Rated Frequency Fn | 50HZ |
| Accuracy | class B/1.0 for active;class 2.0 for reactive |
| pulsating Indicator | LED |
| pulsating(meter constant) | 1000 imp/kwh;1000 imp/kvarh |
| Environment | |
| Temperature range | operation:-40-70℃ |
| storage:-40-85℃ | |
| port ect ion Degree | IP51 in protective enclosure |
| Insulation class | II |
| Typical power consumption | |
| voltage circuit active lap parent power atun | ≤1.5W/8VA |
| current circuit apparent power at Ib | <1VA |
| LCD Display | Dot Matrix type,backlight supported |
| communication Interface | RS485 port,up to38400 b ps |
| weight of Meter | About0.3kg |
| Dimension(LXW XD) | 90x52.5x62mm |
WHY CHOOSE US
Deep industry accumulation: Since its establishment in 2005, it has more than 20 years of industry experience, has been deeply involved in the field of electric meters, has a deep understanding of market demand and technological development, and can provide customers with practical products and services.
Strong production capacity: The annual production capacity reaches more than 7.5 million units, equipped with fully automatic production lines and industry-leading intelligent equipment, realizing intelligent material management, transportation and warehousing, which can efficiently meet large-scale procurement needs.
FAQ
What is the accuracy level of a three-phase rail meter?
Common three-phase rail meters have active accuracy up to1.0S, reactive accuracy of 2.
What are the voltages of the electric meter?
There are many different voltage specifications, the most common ones are 3×230V and 3×400V.
What is the operating temperature and humidity range of the meter?
The general operating temperature range is -40℃~ +70℃. Most three-phase rail meters use special circuit designs and materials, and can work stably within this temperature and humidity range.
