-Main Features
Active/Reactive Energy Measurement
5TE Wide
Modbus Interface
Anti-Tampering Capability(Abnormality Detection, Event Logs, Sealable Casing)
Provide Monthly, Load, And PQ Profiles For Billing And Analysis
MID Certificate
-Specification
Type
Three Phase Four Wire DIN Rail CT Meter
Standards
EN 50470-1, EN 50470-3, IEC 62053-23
Voltage
Rated voltage Un
Voltage range
3x230/400V
80%Un 120%Un
Current
Minimum current Imin
Reference current Ib
Maximum current Imax
Starting current Ist
0.01A
1A
6A
0.1%In
Rated Frequency Fn
50Hz
Accuracy
Class C for active, Class 2 for reactive
Pulsating Indicator
Pulsating (meter constant)
LED and S0 interface
10000imp/kWh, 10000imp/kvarh, configurable for S0 interface
10000imp/kWh, 10000imp/kvarh, configurable for S0 interface
Environment
Temperature range
Operation: -25 55℃
Storage: -40 70℃
Protection Degree
IP 51 in protective enclosure
Insulation Class
II
Typical Power Consumption
Voltage circuit active/apparent power at Un
Current circuit apparent power at Ib
＜2W/10VA
＜1VA
LCD Display
8 digits with configurable decimal place, backlight supported
Communication Interface
RS485 with screw type, maximum upto 38400bps
I/O Interface
1 Relay output
4*Output
4*Output
Weight Of Meter
About 0.3kg
Dimension(LxWxD)
86.0 x 87.5 x 62.0mm
