Primarily used in residential complexes, commercial buildings, and aging pipeline upgrades, it replaces clog-prone mechanical water meters, adapts to complex water quality (including sediment and rust), and demonstrates superior long-term stability compared to conventional meters. Featuring an 11-digit, multi-line LCD display for clear visualization of total volume and instantaneous flow, it supports automatic meter reading and is compatible with infrared, NFC,wMBus, NB-IoT and LoRaWAN communication technologies, enabling remote monitoring and management.
Dimension
| Nominal Diameter (mm) | DN15 | DN20 | DN25 |
| Length (L1, mm) | 96 | 96 | 96 |
| Length (L, mm) | 110 | 130 | 150 |
| Height (H, mm) | 98 | 102 | 107 |
| Width (W, mm) | 96 | 96 | 96 |
| Connection thread on meter | G3/4B | G1B | G1 1/4B |
| Connection thread of coupling | R1/2B | R3/4B | R1B |
Technical Specifications
Wide Range Valve-controlled Ultrasonic Water Meter Technical Advantages
- Ultra-Wide Dynamic Range: R800 flow range ratio achieves droplevel measurement accuracy, with ≤±2% error in low-flow detection.
- Dual-Power Supply Design: Separate power modules for metering and functional circuits ensure dual protection for measurement precision and system stability, effectively suppressing common-mode interference to guarantee long-term data reliability.
- Intelligent Sensing System: Built-in high-precision pressure sensors monitor pipeline pressure in real time, paired with a patented temperature compensation algorithm for dynamic calibration without additional sensors.
- Precise Valve Control: Supports remote adjustment of physical valve opening (5 adjustable positions: 0°, 25°, 50°, 75°, 100°).
- Omni-Directional Installation: U0D0 design eliminates straight pipe requirements, allowing horizontal/vertical installation without compromising accuracy.
- Data Storage Security: Power-cut protection ensures storage of hourly/daily/monthly/annual records, with data retention >15 years.
- Bidirectional Flow Measurement: Independently measures forward/reverse flow, with real-time flow direction display.
- Military-Grade Protection: IP68 rating with triple rubber sealing + full potting technology, ensuring zero leakage.
- Long-Life Design: No moving mechanical parts; built-in lithium-manganese battery reduces self-discharge (<1%/year), with theoretical lifespan ≥15 years.
- High-Temperature Adaptability: T70 rating guarantees stable operation at 70°C
- Alarms: Covering open cover alarm, Overcurrent alarm, Empty pipe alarm, Leakage alarm, Battery low voltage alarm, Overtemperature alarm, Overvoltage alarm.
- Errors: Including magnetic tampering, Physical tampering, Network tampering, Valve failure.
- Display: Water flow direction, Date and time, Signal value, GPS location, NFC enablement status,Storage mode/Verification mode/Factory mode,Valve opening degree, Battery level, Temperature,Pressure value.
- wM-Bus：433 or 868 MHz OMS T1;
- NB loT;
- LoRaWAN ：EU863-870, AS923, AU915-928,US902-928, IN865-867 channel plans;
- Instrumentation Parameterization：Direct acquisition of meter end information via NFC or infrared interface
- M ID(2014/32/EU)
- OIML R49
- OMS compliance certificate
- WRAS(UK)
You may be interested in
What exactly does "wide range" mean? What is its value for large-volume projects?
A wide range refers to a water meter maintaining high accuracy across a wide flow range (typically R250/R400 and above).
Its value for large-volume projects lies in:
No missed readings at low flow rates (minor nighttime water usage, dripping)
No distortion at high flow rates (peak water usage, centralized water supply)
Reduced complaints and metering disputes, lowering operational risks
A unified model covering multiple operating conditions, simplifying procurement and inventory management.
How stable and long-term are ultrasonic water meters in large-scale, long-term use?
Ultrasonic water meters have no mechanical moving parts and therefore no wear issues, making them particularly suitable for long-term, large-scale installations.
Advantages include:
Strong resistance to water impurities, less prone to jamming
Long-term stable metering with minimal accuracy degradation
Typical design life of 10–15 years or more
Suitable for high-frequency meter readings and smart water management systems.
How to ensure product consistency and quality control during large-volume procurement?
For bulk projects, we typically offer:
Full-process calibration and factory testing (unit-by-unit or random sampling)
Compliance with international standards such as ISO 4064 / MID / OIML R49
Batch traceability (SN / production records / calibration data)
Support for third-party testing or project sampling requirements
Ensuring consistent performance and reliable data for every batch of water meters within the same project.
