Three Phase Three Wire DIN Rail Meter function
Active energy measurement:Focusing on the accurate measurement of active energy in the circuit and providing users with accurate power consumption data is one of the core functions of power metering.
Single energy direction :Only the power flowing from the power grid to the power consumption equipment is measured, which is suitable for power consumption scenarios with fixed energy flow direction.
1TE width:"1TE" here usually refers to the installation width unit occupied by the device on the DIN rail, which can be easily installed in a limited installation space.
Modbus interface:Equipped with a standard Modbus communication interface, it can realize data transmission and communication with other smart devices or systems.
Applicable to AC electric vehicle charging stations and any itemized billing applications:It can accurately measure the power consumption during the charging process of electric vehicles.
MID certificate:Possessing a MID (Measuring Instruments Directive) certificate indicates that the meter complies with the relevant EU directive requirements on measuring instruments.
| Specification | A132 |
| Type | Three phase Three wire DIN Rail Meter |
|---|---|
| standards | EN 50470-3:2022,IEC 62053-21/23:2020,IEC 62052-31:2015,UL61010-1,UL61010-2-030 |
| voltage | |
| Rated voltage un | 3x230/400v |
| voltage range | 70%un~140%un |
| current | |
| Minimum current Imin | 0.25A |
| Reference current Ib | 5A |
| Maximum current Imax | 80A |
| starting current ist | 0.4%Ib |
| Rated Frequency Fn | 50HZ |
| Accuracy | class B/1.0 for active;class 2.0 for reactive |
| pulsating Indicator | LED |
| pulsating(meter constant) | 1000 imp/kwh;1000 imp/kvarh |
| Environment | |
| Temperature range | operation:-40-70℃ storage:-40-85℃ |
| port ection Degree | IP51 in protective enclosure |
| Insulation class | II |
| Typical power consumption | |
| voltage circuit active lap parent power atun | ≤1.5W/8VA |
| current circuit apparent power at Ib | <1VA |
| LCD Display | Dot Matrix type,backlight supported |
| communication Interface | RS485 port,up to 38400 bps |
| weight of Meter | About 0.3kg |
| Dimension(L×W ×D) | 90×52.5×62mm |
Three Phase Three Wire DIN Rail Meter manufacturer
Easy and efficient installation: It adopts the standard 35mm DIN rail installation method. There is no need to drill holes on the wall to fix it. You only need to snap the meter directly into the rail to complete the installation, which greatly reduces the complexity and time cost of manual operation. It has obvious advantages in large-scale projects or occasions that require rapid deployment. And replacement and maintenance can also be carried out without affecting other equipment, which is convenient and fast.
Accurate and reliable measurement: Using advanced electronic measurement technology, it can accurately measure parameters such as voltage, current, power factor, etc., and achieve high-precision electric energy measurement. At the same time, the meter has strong anti-interference ability, which can effectively resist the influence of external factors such as electromagnetic interference and temperature changes, ensure the stability and reliability of measurement, and provide accurate data for electric energy measurement.
FAQ
Q:What is a three-phase, three-wire DIN rail energy meter?
A:The instrument used to measure the electric energy of three-phase three-wire circuit adopts DIN rail installation, and has the characteristics of small size and easy installation.
Q:What are the main functions of a three-phase three-wire DIN rail meter?
A:Real-time measurement of three-phase active/reactive energy, electrical parameter monitoring, communication interface, alarm and protection
Q:What should I pay attention to when installing a three-phase, three-wire DIN rail meter?
A:Confirm that the circuit is a three-phase three-wire system. The voltage level must be consistent with the rated parameters of the meter. Connect the three-phase live wire according to the terminal block markings. The current loop must be connected in series with a current transformer to ensure correct polarity.
