Three Phase Four Wire CT/CT-VT Operated Meter -- E3016-SA

Active/Reactive/Apparent Energy Measurement Various Extended Communication Technology Capability Wide Operating Voltage Range Smart Meter Features (Interoperability,Remote Communication,Load Control) Anti-Tampering Capability (Abnormality Detection, Event Logs, Sealable Casing) Provide Daily,Monthly,Load And PQ Profiles For Billing And Analysis MID& IEC Certificates High Degree Of Accuracy,Type(3P3W/3P4W) Is Configurable

-Main Features

Active/Reactive/Apparent Energy Measurement

Various Extended Communication Technology Capability

Wide Operating Voltage Range

Smart Meter Features (Interoperability,Remote Communication,Load Control)

Anti-Tampering Capability (Abnormality Detection, Event Logs, Sealable Casing)

Provide Daily,Monthly,Load And PQ Profiles For Billing And Analysis

MID& IEC Certificates

High Degree Of Accuracy,Type(3P3W/3P4W) Is Configurable

-Specification

Type

Three Phase Four Wire CT/CT-VT Operated Meter

Standards

EN 50470-1, EN 50470-3, IEC 62052-11, IEC 62053-22/23,
IEC62056-21, IEC62056-61, IEC62059-31

Voltage

Rated voltage Un

Voltage range

57.7V~240V
80%Un~115%Un

Current

Minimum current Imin

Reference current Ib

Maximum current Imax

Starting current Ist

0.01A
1A, 1.5A
6A or 10A
0.1%Ib

Rated Frequency Fn

50/60Hz

Accuracy

Class C/0.5S for active; Class 2.0 for reactive

Pulsating Indicator

Pulsating (meter constant)

LED
10000imp/kWh;10000imp/kvarh

Environment

Temperature range

Operation: -25~75℃
Storage: -40~85℃

Protection Degree

IP 54

Insulation Class

Typical Power Consumption

Voltage circuit active/apparent power at Un

Current circuit apparent power at Ib

＜2W/10VA
＜1VA

LCD Display

8 digits with configurable decimal place, backlight supported

Backup Power Supply

Replaceable battery and Internal super capacitor

RTC

Provides RTC with clock accuracy according to IEC62054-21

Communication Interface

2*RS485(RJ45 type) with power output 12V,max 5W
1*Optical port
1*Module compartment (Cellular,RF,PLC or LoRa)

Communication Protocol

DLMS/COSEM, Support data transportation encryption (Suite 0)

I/O Interface

1*Signal Input
2*Signal Outputs
1*Control Outputs

Weight Of Meter

About 1.4kg

Dimension(LxWxD)

290.1 × 178.0 ×75.0mm

E3015-SA-T
